Aluminum Service Entrance(SE)Cable
Aluminum SE cable – trusted for residential service entrance wiring.
Lightweight and flexible solution for overhead or underground entry.
SE cable with tough insulation for safe, long-term home power supply.
Cost-effective aluminum conductor cable for utility connections.
UL-listed SE cable – easy to install, built to last.
Application
Aluminum Service Entrance (SE) Cable is specifically designed for power supply from utility lines to residential or light commercial buildings, supporting both above-ground (SEU) and underground (SER) service entrance applications. It consists of compact stranded aluminum conductors, with PVC insulation and an overall sunlight-resistant PVC jacket, offering durability and long service life in outdoor environments.
SE cables are available in two main types:
SEU (Service Entrance, Unarmored): Typically used for single-phase residential mains, with a two-conductor plus ground configuration.
SER (Service Entrance, Reinforced): Contains multiple conductors and a bare aluminum ground, often used for panel feeders or subpanel connections.
These cables are UL-listed and rated 600V, with temperature ratings up to 90°C (wet or dry conditions). Their lightweight construction, flexibility, and corrosion resistance make installation easy in conduit or open air.
Manufactured in compliance with UL 44 and UL 854, Aluminum SE Cables are a cost-effective and code-compliant solution for reliable power distribution in North American residential and light commercial projects.
Specifications
| Category | Technical Description | Typical Applications |
|---|---|---|
| Cable Type | SE (Service Entrance) Cable with aluminum conductors, available in two variants: Type SEU (Unarmored) and Type SER (Round with Ground) | Used to deliver main power from meter base to electrical panels in buildings |
| Conductor Material | – 1350 Series Aluminum or AA-8000 Series aluminum alloy, stranded for flexibility and weight reduction | Lighter and more cost-effective than copper for long runs |
| Construction | – Type SEU: 2 or 3 insulated conductors + bare neutral- Type SER: 2, 3 or 4 insulated conductors including ground | Both types include a PVC jacket for overall protection |
| Insulation & Jacket | – XHHW-2 insulation on phase and neutral conductors- Sunlight-resistant gray PVC sheath | Rated for wet and dry locations, both indoor and outdoor |
| Voltage Rating | Commonly rated for 600 volts, with temperature rating up to 90°C (194°F) | Suitable for residential, commercial, and light industrial service entrances |
| Standards Compliance | Complies with UL 44, UL 854, NEC Article 338, ASTM B800/B801, AA-8000 series standards | Listed for use by UL (Underwriters Laboratories) |
Parameter
Aluminum Service Entrance(SE)Cable Reference Standard
| Conductor | Strandng | Nomnina 0.D.(MIs) | Allowable Ampacties | Approdimat e Net Weight Per 1000(Lbs) | Standard Package | ||||
| SizeConst, AWG or kcmil | Phase Conductor & Neutral | EquipmentGround Conduclor | 60℃ | 75℃ | 90℃ | Dwelling | |||
| SER Aluminum Two-Conductor Wih Bare Ground (Formerly referred to as “EZ-SE”) | |||||||||
| 6-6-6 | 7 | – | 650 | 40 | 50 | 60 | – | 150 | B |
| 4-4-4 | 7 | – | 745 | 55 | 65 | 75 | – | 203 | B |
| 4-4-6 | 7 | – | 745 | 55 | 65 | 75 | – | 203 | B |
| 2-2-2 | 7 | – | 864 | 75 | 90 | 100 | 100 | 290 | B |
| SER Auminum Three Conduclor With Bare Ground (Formerly relerred to as “Four Conductor”) | |||||||||
| 8-8-8-8 | 1 | 1 | 612 | 30 | 40 | 45 | – | 136 | B |
| 6-6-6-6 | 7 | 7 | 717 | 40 | 50 | 60 | – | 196 | B |
| 4-4-4-6 | 7 | 7 | 823 | 55 | 65 | 75 | – | 252 | B |
| 2-2-2-4 | 7 | 7 | 956 | 75 | 90 | 100 | 100 | 359 | B |
| 1-1-1-3 | 8 | 7 | 1079 | 85 | 100 | 115 | 110 | 449 | C |
| 1/0-1/0-1/0-2 | 10 | 1 | 1168 | 100 | 120 | 135 | 125 | 540 | C |
| 2/0-2/0-2/0-1 | 12 | 1 | 1264 | 115 | 135 | 150 | 150 | 652 | C |
| 3/0-3/0-3/0-1/0 | 16 | 1 | 1371 | 130 | 155 | 175 | 175 | 786 | C |
| 4/0-4/0-4/0-2/0 | 19 | 1 | 1496 | 150 | 180 | 205 | 200 | 960 | C |
| 250-250-250-3/0 | 22 | 1 | 1839 | 170 | 205 | 230 | 225 | 1458 | C |
| SER Aluminum Four Conductor With Bare Ground (Formerly relerred to as “Fiwe Conductor”) | |||||||||
| 2-2-2-2-4 | 6 | 7 | 1059 | 75 | 90 | 100 | 100 | 452 | B |
| 2/0-2/0-2/0-2/0-1 | 12 | 1 | 1404 | 115 | 135 | 150 | 150 | 827 | C |
| 4/0-4/0-4/0-4/0-2/0 | 19 | 1 | 1672 | 150 | 180 | 205 | 200 | 1228 | C |
| 250-250-250-250-3/0 | 22 | 1 | 1847 | 170 | 205 | 230 | 225 | C | |
| SEU Aluminum Two Conductor With Bare Conentric Ground (Formerly relerred to as “Three Conductor”) | |||||||||
| Conductor | Strandng | Nomnina 0.D.(MIs) | Allowable Ampacties | Approdimat e Net Weight Per 1000(Lbs) | Standard Package | ||||
| SizeConst, AWG or kcmil | Phase Conductor & Neutral | EquipmentGround Conduclor | 60℃ | 75℃ | 90℃ | Dwelling | |||
| 6-6-6 | 7 | 8 | 430×687 | 40 | 50 | 60 | – | 145 | B,C,E |
| 4-4-4 | 7 | 12 | 499×800 | 55 | 65 | 75 | – | 198 | B |
| 4-4-6 | 7 | 15 | 474×775 | 55 | 65 | 75 | – | 181 | B |
| 2-2-2 | 7 | 14 | 569×925 | 75 | 90 | 100 | 100 | 283 | B,C,G |
| 2-2-4 | 7 | 18 | 554×910 | 75 | 90 | 100 | 100 | 259 | B,C,G |
| 2/0-2/0-2/0 | 18 | 18 | 736×1221 | 115 | 135 | 150 | 150 | 514 | C |
| 2/0-2/0-1 | 18 | 14 | 720×1205 | 115 | 135 | 150 | 150 | 468 | C |
| 4/0-4/0-4/0 | 18 | 18 | 878×1462 | 150 | 180 | 205 | 205 | 765 | C |
| 4/0-4/0-2/0 | 18 | 18 | 835×1419 | 150 | 180 | 205 | 205 | 691 | C |
| Table values rellect XHHW-2 conduclors, Alowable ampacities shown are for general use as specifed by the Nalional EleclricalCcde.2011 Edilion,Seclion 310.15. | Package Codes: B-1.000′ C- 500′ E-250′ G-200′ | ||||||||
| 60℃ – When terminated to equipment for circults ra ted 100 amperes or less or marked for 14 through 1 AWG conductors, SecNEC Anicle 338,10 (B)(4). | |||||||||
| 75℃ – When terminated to equipment for circuls ra ted 100 amperes or marked for conductors larger than 1 AWG conductorsMay not apply, see NEC Aricle 338,10 (B)(4). | |||||||||
| 90℃-Wet or cnylocations, For ampacity de-rating purposes. | |||||||||
| Dwelling – For units, conductors shal be permitled at isled ampacllies as 120/240-vot, 3-wire, singie-phase services and feedersper NEC Article 310,15. | |||||||||
| *For compact-stranded construction,the number of wires, as perm lted by U Standard 854 and ASTM B-801 may be reduced asfollows:19-wire constructions-i8 wires minimum. | |||||||||
